Special Junction Box For Adhesive Filled High-Power Components
  • Special Junction Box For Adhesive Filled High-Power Components
  • Special Junction Box For Adhesive Filled High-Power Components
  • Special Junction Box For Adhesive Filled High-Power Components

Special Junction Box For Adhesive Filled High-Power Components

Key Advantages:
Achieves highly competitive cost control while ensuring high reliability. TÜV-certified and featuring a potted structure, it is the preferred solution for high-power, mainstream modules seeking an optimal balance of performance and cost.

Inquiry Now
  • Product Specifications
  • Get A Quote
  • Product Features:
    Enhanced circuitry for high power output, offering excellent electrical insulation strength. The housing material features superior UV resistance, ensuring no fading or cracking during long-term outdoor exposure. Extremely easy to use, making it suitable for rapid assembly-line integration.

    Applications:
    Widely used in mainstream 550W+ high-power monocrystalline modules; ideal for large-scale ground-mounted solar power plants.

    Common Issues & Solutions:
    Issue: Diode failure under extreme high temperatures.
    Solution: The internal design incorporates dedicated thermal conduction paths, and the selected diodes feature high surge-withstand capability, ensuring stability during full-load operation at high temperatures.

    Important Note: Strictly control the soldering temperature when attaching ribbon conductors to avoid damaging the internal encapsulation structure.

    Parameter Specification
    Overall Dimensions L 117×W 90×H 22mm (Without wire, with cover closed)
    Rated Current 10A
    Withstand Voltage 1000V DC (TUV)
    Safety Class Class Ⅱ
    Operating Environment Range Temperature: -40℃ ~ +85℃, Humidity: <95%
    Protection Class IP65
    Flame Retardant Class UL94-V0 (Only for plastic material parts)
    Contact Resistance ≤5 mΩ
    Pollution Degree Class II
    Overvoltage Category Class III
    Cable Specification 4mm²
